--- title: Tri-Sen Turbomachinery Controls DSC100 description: DSC100, a digital servo controller typically used on steam and gas turbines to position proportional or integrating, hydraulic or pneumatic actuators --- [![26TRIS065-Tri-Sen 50 years logo-R2](https://tri-sen.com/hs-fs/hubfs/Assets/26TRIS065-Tri-Sen%2050%20years%20logo-R2.png?width=180&height=70&name=26TRIS065-Tri-Sen%2050%20years%20logo-R2.png "26TRIS065-Tri-Sen 50 years logo-R2")](https://tri-sen.com/?hsLang=en) [![26TRIS065-Tri-Sen 50 years logo-R2](https://tri-sen.com/hs-fs/hubfs/Assets/26TRIS065-Tri-Sen%2050%20years%20logo-R2.png?width=90&height=35&name=26TRIS065-Tri-Sen%2050%20years%20logo-R2.png "26TRIS065-Tri-Sen 50 years logo-R2")](https://tri-sen.com/?hsLang=en) ![Dsc100 Front](https://tri-sen.com/hubfs/TriSen_August2020/Image/DSC100-Front.png) The DSC100 is a compact digital servo controller that’s typically used on steam and gas turbine applications to position proportional or integrating, hydraulic or pneumatic actuators, based on the demand signal from the turbine controller. It's easy to configure, easy to calibrate, easy to operate, easy to install and, easy to replace on-line.  ![Dsc100 Front](https://tri-sen.com/hubfs/TriSen_August2020/Image/DSC100-Front.png) - Overview - Hardware - Software - Specifications ## Application Overview The DSC100 is a compact digital servo controller that’s typically used on steam and gas turbine applications to position proportional or integrating, hydraulic or pneumatic, actuators based on the demand signal from the turbine controller. The DSC100 positions the actuator by sending a redundant, configurable position demand to the actuator and senses the actuator position using single or dual position feedback devices (LVDTs, RVDTs or DC current). The position demand signal can be sent to the DSC100 via Network, Serial or 0-25mA connections. ![Dsc100 Blue Application](https://tri-sen.com/hubfs/TriSen_August2020/Image/DSC100-black-application.png) ### FEATURES - Compact Size - Intuitive Configuration and Calibration - Modbus TCP Communications and Configuration Interface - Serial Modbus (485) Communications and Configuration Interface - Redundant 3,4,5,& 6 wire LVDT / RVDT Position Feedback inputs - Redundant configurable (+/-250mA, +/-100mA, +/-50mA, +/-10mA) Actuator Outputs - DIN rail mounted - Redundant 24vdc Powered [![Dsc100 Rightside](https://tri-sen.com/hubfs/TriSen_August2020/Image/DSC100-RightSide.png) ](https://tri-sen.com/hubfs/DSC100-RightSide.png?hsLang=en) [![Dsc100 Front](https://tri-sen.com/hubfs/TriSen_August2020/Image/DSC100-Front-small.png) ](https://tri-sen.com/hubfs/DSC100-Front.png?hsLang=en) [![Dsc100 Leftside](https://tri-sen.com/hubfs/TriSen_August2020/Image/DSC100-LeftSide.png) ](https://tri-sen.com/hubfs/DSC100-LeftSide.png?hsLang=en) [![Dsc100 Backview](https://tri-sen.com/hubfs/TriSen_August2020/Image/DSC100-BackView.png) ](https://tri-sen.com/hubfs/DSC100-BackView.png?hsLang=en) The DSC100 is a DIN rail mountable, fully functional sub-compact digital servo controller, that's comprised of two pieces - a base and the controller module. The controller module can be replaced without disturbing the field wiring on the base. ### FEATURES - Compact Size - Intuitive Configuration - Intuitive Calibration - Modbus TCP Communications and Configuration interface - Serial Modbus (485) Communications and Configuration interface - Redundant 3,4,5,& 6 wire LVDT / RVDT Position Feedback inputs - Redundant, configurable (+/-250mA, +/-100mA, +/-50mA, +/-10mA) actuator outputs - DIN rail mountable - Redundant 24vdc powered ### Input/Output - (2) Redundant 3, 4, 5, and 6 wire LVDT / RVDT Position Feedback inputs - (2) Redundant DC Current / Voltage Position Feedback inputs - (1) “Hard-wired” position command input (0-25mA) - (2) Configurable current Actuator Outputs - (1) Digital Reset Command input - (1) Digital External Shutdown Input - (1) Alarm Output - (1) Shutdown Output - (1) Modbus RS-485 Connection - (1) Modbus TCP Connection ![Ts Icon 02](https://tri-sen.com/hubfs/TriSen_August2020/Image/ts-icon-02.svg) ## Configuration Tool The DSC100 comes with an easy-to-use Windows-based software application that allows you to configure the DSC100 from a PC. Calibrating and configuring the DSC100 is fast and easy with an autocalibrate function, tuning, manual valve stroking and on-line adjustment functionality, Configurations can be easily downloaded or uploaded to or from the DSC100 and a comparison feature makes it easy to identify differences between two configuration files. ![Ts Icon 20](https://tri-sen.com/hubfs/TriSen_August2020/Image/ts-icon-20.svg) ## Integrated Help Detailed integrated help minimizes the need to refer to the User’s Guide during configuration. [![Dsc100 Trend](https://tri-sen.com/hubfs/TriSen_August2020/Image/DSC100-Trend.jpg) ](https://tri-sen.com/products/dsc100#modal-3) ![Dsc100 Trend](https://tri-sen.com/hubfs/TriSen_August2020/Image/DSC100-Trend.jpg) ## Trending The DSC100 configuration tool also includes a “built-in” trending tool to help validate tuning and graphically demonstrate valve response. Additionally, the DSC100 also records historical information in a .CSV file that can be easily imported into a data management tool like Excel for review. | Feature | Description | | --- | --- | | Inputs | (2) Redundant Inputs | | Input Voltage | 18-32VDC，1A | | Feature | Description | | --- | --- | | Input | (1) 0-25mA |   | Feature | Description | | --- | --- | | Voltage Range | 3.0 - 4.0 Vrms | | Frequency Range LVDT1 | 2.7 - 3.1 kHz | | Frequency Range LVDT2 | 2.1 - 2.5 kHz | | Maximum Load | 120 mA | | Accuracy | 0.2% of full scale @ 25 °C | | Temperature Sensitivity | 150 ppm/°C | | Feature | Description | | --- | --- | | Connectivity | 3-wire，4-wire，6-wire | | Common mode rejection | –60 dB @ 60 Hz | | Input Filter | 10 ms lag | | Digital Resolution | 14 bits | | Linearity | 0.1% of full scale | | Temperature Sensitivity | 150 ppm/°C | | Feature | Description | | --- | --- | | Current Range | 2, isolated, normally open contact, solid state relays | | Maximum Voltage | 24 VDC | | Common Mode Rejection | 3A | | Input Impedance | 250 Ω | | Input Filter | 5 ms lag | | Digital Resolution | 14 bits | | Linearity | 0.1% of full scale | | Temperature Sensitivity | 150 ppm/°C | | Feature | Description | | --- | --- | | Output Channel | (2) Channels – Current | | Output Range (configurable) | ±10 mA, ±25 mA, ±50 mA, ±100 mA, ±250 mA | | Resolution | 14 bits | | Accuracy | 1% | | Linearity | 0.2% of full scale | | Dither | 0–10%, 25% duty cycle @ 25 Hz | | Output Filter | 6 ms lag | | Feature | Description | | --- | --- | | Output Channel | (2) Channels (Alarm/Shutdown) | | Output Type | Relay | | Maximum Current | 500mA | | Isolation Voltage | 500 Vrms | | Feature | Description | | --- | --- | | Input Channel | (6) channels (Reset，Shutdown, 4 Reserved) | | Input Type | “Dry-contact” Input | | Isolation Voltage | 500 Vrms | | Operation Current | 10 mA | | Feature | Description | | --- | --- | | Hardware Interface | RS485 | | Isolation Voltage | 500 Vrms | | Station Address | Set by 8-bit coding switch | | Communication Protocol | Modbus | | Baud Rate | Coding switch selectable; 4.8, 9.6, 38.4, 115.2 Mbps | | Feature | Description | | --- | --- | | Hardware Interface | RJ45 | | Communication Protocol | Modbus TCP | | Rate | 100M | | Feature | Description | | --- | --- | | PID algorithm execution speed | 10 ms | | Feature | Description | | --- | --- | | Temperature (operational/storage) | -15°C – 60°C / -25ºC – 75°C | | Relative Humidity (operational and storage) | 5%-95%，Non-condensing | ## Dimensions ![Dimensions](https://tri-sen.com/hubfs/TriSen_August2020/Image/DSC100-dimensions-cropped.png) ## DSC100 DOWNLOADS - [DSC100 Product Brochure](https://go.tri-sen.com/dsc100-product-brochure-download?hsLang=en) Help ## Privacy Statement Our privacy policy is simple: We will never share your information with anyone. ### Contact Us
